请问ADS1263如何正确使用PGA功能？

ADS1263是一款24位模数转换器（ADC），具有可编程增益放大器（PGA）功能。根据您的描述，您希望使用差分输入IN2和IN3，并使能PGA功能，增益为32倍。下面是一个基本的程序示例，用于正确使用PGA功能：

```c
#include
#include

// 定义ADS1263的寄存器地址
#define ADS1263_REG_CONFIG1 0x00
#define ADS1263_REG_CONFIG2 0x01
#define ADS1263_REG_CONFIG3 0x02
#define ADS1263_REG_OFFSET 0x03
#define ADS1263_REG_GAIN 0x04
#define ADS1263_REG_LOFFS 0x05
#define ADS1263_REG_HOFFS 0x06
#define ADS1263_REG_CONFIG4 0x07

// 定义ADS1263的配置参数
#define ADS1263_CONFIG1_MODE_CONTINUOUS 0x00
#define ADS1263_CONFIG1_MODE_SINGLE_SHOT 0x01
#define ADS1263_CONFIG1_MODE_IDLE 0x02
#define ADS1263_CONFIG1_MODE_RESET 0x03
#define ADS1263_CONFIG1_MODE_MASK 0x03

#define ADS1263_CONFIG2_MUX_DIFFERENTIAL 0x00
#define ADS1263_CONFIG2_MUX_SINGLE_ENDED 0x04
#define ADS1263_CONFIG2_MUX_MASK 0x04

#define ADS1263_CONFIG3_PGAGAIN_1 0x00
#define ADS1263_CONFIG3_PGAGAIN_2 0x20
#define ADS1263_CONFIG3_PGAGAIN_4 0x40
#define ADS1263_CONFIG3_PGAGAIN_8 0x60
#define ADS1263_CONFIG3_PGAGAIN_16 0x80
#define ADS1263_CONFIG3_PGAIN_32 0xA0
#define ADS1263_CONFIG3_PGAGAIN_MASK 0xE0

#define ADS1263_CONFIG4_REF_INTERNAL 0x00
#define ADS1263_CONFIG4_REF_EXTERNAL 0x01
#define ADS1263_CONFIG4_REF_MASK 0x01

// 初始化ADS1263
void ads1263_init(void) {
    // 配置寄存器
    ads1263_write_register(ADS1263_REG_CONFIG1, ADS1263_CONFIG1_MODE_CONTINUOUS);
    ads1263_write_register(ADS1263_REG_CONFIG2, ADS1263_CONFIG2_MUX_DIFFERENTIAL);
    ads1263_write_register(ADS1263_REG_CONFIG3, ADS1263_CONFIG3_PGAIN_32);
    ads1263_write_register(ADS1263_REG_CONFIG4, ADS1263_CONFIG4_REF_INTERNAL);
}

// 读取ADC值
uint32_t ads1263_read_adc(void) {
    uint32_t adc_value;
    // 启动转换
    ads1263_start_conversion();
    // 等待转换完成
    while (!ads1263_check_conversion_complete());
    // 读取转换结果
    adc_value = ads1263_read_conversion_result();
    return adc_value;
}

// 模拟的ADS1263寄存器写入函数
void ads1263_write_register(uint8_t reg, uint8_t value) {
    // 实现寄存器写入的具体代码
}

// 模拟的ADS1263转换启动函数
void ads1263_start_conversion(void) {
    // 实现转换启动的具体代码
}

// 模拟的ADS1263转换完成检查函数
bool ads1263_check_conversion_complete(void) {
    // 实现转换完成检查的具体代码
    return true;
}

// 模拟的ADS1263转换结果读取函数
uint32_t ads1263_read_conversion_result(void) {
    // 实现转换结果读取的具体代码
    return 0;
}

int main(void) {
    ads1263_init();
    while (1) {
        uint32_t adc_value = ads1263_read_adc();
        // 处理ADC值
    }
    return 0;
}
```

这个示例程序展示了如何初始化ADS1263，配置PGA功能，并读取ADC值。请注意，您需要根据您的硬件平台实现`ads1263_write_register`、`ads1263_start_conversion`、`ads1263_check_conversion_complete`和`ads1263_read_conversion_result`函数。希望这个示例对您有所帮助！
